GB/T 8163 Grade 10# 20# Seamless Steel Pipe For Conveying Liquid

MOQ: 1
Price: Negotiable
Standard Packaging: Standard Export Packing
Delivery Period: 7~30 working days
Payment Method: L/C, D/A, D/P, T/T, Western Union
Detail Information
Product Description
Detail Information
Place of Origin
cangzhou
Brand Name
BaoYang
Certification
CE & ISO
Model Number
GB/T 8163 Grade 10# 20#
Document
Product Brochure PDF
Name:
Seamless Steel Pipe
Process:
Hot Rolled Cold Rolled Cold Drawn
Standards:
GB/T 8163 Grade 10# 20#
Material:
Carbon Steel Alloy Steel
Wall Thickness:
1-20mm (0.04 Inch - 0.78 Inch)
Outer Diameter:
6-2500mm
Processing Service:
Bending, Punching, Cutting
Usage:
Pipeline Transport, Oil/Gas Drilling, Machinery Industry
Minimum Order Quantity:
1
Price:
Negotiable
Packaging Details:
Standard Export Packing
Delivery Time:
7~30 working days
Payment Terms:
L/C, D/A, D/P, T/T, Western Union
Highlight:

gb seamless steel pipe

,

gb seamless stainless steel pipe

,

gb/t 8163 seamless steel pipe

Product Description

GB/T 8163 Grade 10# and 20# Seamless Steel Pipes for Conveying Liquids:

Product Description: GB/T 8163 Grade 10# and 20# Seamless Steel Pipes are designed for the conveyance of liquids in various industrial applications. These pipes are manufactured in accordance with the Chinese national standard GB/T 8163, which specifies the requirements for seamless steel pipes suitable for transporting liquids, including water, oil, and gas. The pipes are made from low carbon steel, with the '10#' and '20#' grades indicating the steel's carbon content, which affects the strength and weldability of the pipes.

Product Parameter Specifications:

Parameter Specification Units
Standard GB/T 8163-2018 -
Grade 10#, 20# -
Outer Diameter Ranges from 6mm to 219mm depending on the specific application mm
Wall Thickness Varies with diameter; specific range per product specification mm
Length Typically 4-12m, customizable based on requirements m
Tolerance As per GB/T 8163-2018 for diameter and wall thickness -

Product Applications:

  1. Water Supply Systems: Utilized in municipal and industrial water supply systems for clean water conveyance.
  2. Oil and Gas Industry: Suitable for transporting oil, natural gas, and petroleum products.
  3. Chemical Industry: Employed in the transportation of corrosive or high-temperature liquids.
  4. Agricultural Irrigation: Used for efficient water delivery in irrigation systems.
  5. Fire Protection Systems: Ideal for fire sprinkler systems and water supply in emergency response.

Types of GB/T 8163 Seamless Steel Pipes:

  • Grade 10#: General-purpose low carbon steel pipes suitable for low to medium pressure liquid conveyance.
  • Grade 20#: Low carbon steel pipes with slightly higher carbon content, offering improved strength for medium pressure applications.

Mechanical Properties:

Property Typical Range/Value for Grade 10# and 20# Units
Tensile Strength 340-510 MPa (10#), 410-590 MPa (20#) MPa
Yield Strength ≥ 205 MPa (10#), ≥ 245 MPa (20#) MPa
Elongation ≥ 22% (for both grades) %

Chemical Composition:

Element Typical Range (%) for Grade 10# and 20#
Carbon (C) 0.07-0.13 (10#), 0.17-0.23 (20#)
Manganese (Mn) 0.35-0.65 (10#), 0.35-0.65 (20#)
Phosphorus (P) ≤ 0.035 (10#), ≤ 0.035 (20#)
Sulfur (S) ≤ 0.035 (10#), ≤ 0.035 (20#)

Note: The specific mechanical properties and chemical composition can vary based on the manufacturing process and the specific requirements of the application. It is essential to consult the manufacturer's technical documentation for precise specifications and to ensure compatibility with the intended application.



GB/T 8163 Grade 10# 20# Seamless Steel Pipe For Conveying Liquid 0GB/T 8163 Grade 10# 20# Seamless Steel Pipe For Conveying Liquid 1

Company Profile

GB/T 8163 Grade 10# 20# Seamless Steel Pipe For Conveying Liquid 2

Factory Tour

GB/T 8163 Grade 10# 20# Seamless Steel Pipe For Conveying Liquid 3

team introduction

GB/T 8163 Grade 10# 20# Seamless Steel Pipe For Conveying Liquid 4

Applications

GB/T 8163 Grade 10# 20# Seamless Steel Pipe For Conveying Liquid 5
