GB/T5310 15CrMoG Alloy Seamless Steel Pipe For High Pressure Boiler

Products

High Pressure Boiler Steel Pipe

GB/T5310 15CrMoG Alloy Seamless Steel Pipe For High Pressure Boiler

MOQ:	1
Price:	Negotiable
Standard Packaging:	Standard Export Packing
Delivery Period:	7~30 working days
Payment Method:	L/C, D/A, D/P, T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin

cangzhou

Brand Name

BaoYang

Certification

CE & ISO

Model Number

GB/T5310 15CrMoG

Document

Name:

Seamless Alloy Steel Pipes

Process:

Hot Rolled Cold Rolled Cold Drawn

Standards:

GB/T5310 15CrMoG

Material:

Alloy Steel Pipe

Wall Thickness:

1-30mm (0.04 Inch - 0.78 Inch)

Outer Diameter:

10-324mm

Processing Service:

Bending, Punching, Cutting

Usage:

Pipeline Transport, Oil/Gas Drilling, Machinery Industry

Minimum Order Quantity:

Price:

Negotiable

Packaging Details:

Standard Export Packing

Delivery Time:

7~30 working days

Payment Terms:

L/C, D/A, D/P, T/T, Western Union

Highlight:

15crmog alloy seamless steel pipe

gb alloy seamless pipe

gb/t5310 alloy seamless pipe

Product Description

GB/T5310 15CrMoG Alloy Seamless Steel Pipe for High Pressure Boiler

1. Product Description: GB/T5310 15CrMoG Alloy Seamless Steel Pipe is specifically designed for high pressure boiler applications that demand exceptional heat resistance and mechanical strength. Manufactured from 15CrMoG alloy steel, these pipes are seamless, providing uniform wall thickness and superior structural integrity. The 15CrMoG grade offers excellent creep resistance and is well-suited for use in critical boiler components.

2. Product Parameters:

Parameter	Description
Grade	GB/T5310 15CrMoG
Material	Alloy Steel (Seamless)
Standard	GB/T5310
Size Range	Various diameters and wall thicknesses as per GB/T5310
Length	Standard lengths, customizable upon request
Ends	Plain ends, beveled ends, threaded, or socket-weld ends
Surface Treatment	As-rolled, annealed, or normalized

3. Mechanical Properties:

Property	Typical Requirements
Tensile Strength	≥440 MPa (64,000 psi)
Yield Strength	≥295 MPa (42,500 psi)
Elongation	≥20% in 50 mm (2 in) or 4D, whichever is greater
Hardness	Varies depending on heat treatment

4. Chemical Composition:

Element	Typical Range (%)
Carbon	0.12 - 0.20
Chromium	0.40 - 0.70
Molybdenum	0.40 - 0.60
Manganese	≤1.00
Phosphorus	≤0.025
Sulfur	≤0.025

5. Product Applications:

Boiler Tubes: Used for steam generation in high-pressure boilers.
Superheater and Reheater Tubes: Employed in superheater and reheater sections of steam power plants.
Heat Exchangers: Suitable for use in heat exchangers operating under high pressure and temperature.
Pressure Vessels: Ideal for construction of high-pressure vessels and reactors in petrochemical and refining industries.

6. Product Advantages:

Seamless Construction: Provides a consistent material structure and eliminates potential seam-related failures.
High-Pressure Resistance: Alloy steel offers excellent resistance to high pressures and temperatures.
Creep Resistance: Designed to resist deformation under prolonged exposure to heat, critical in boiler applications.
Weldability: The 15CrMoG grade has good weldability, facilitating easy integration into various systems.
Corrosion Resistance: Enhanced resistance to corrosion and oxidation due to the alloy content.

GB/T5310 15CrMoG Alloy Seamless Steel Pipe For High Pressure Boiler 0
